Series 3250XTF Fixed Windows

Series 3250XTF thermal-strut fixed windows feature a 39mm strut that is crucial for achieving such low U-value window performance. Designed with a 3.25" main frame depth and .125" structural walls, these fixed windows make it possible to meet the needs of any project with energy efficiency as a key driver. The architectural possibilities are endless when designing for schools, universities, government offices, hospitals, military buildings, and other commercial applications.

The Series 3250XTF aluminum window system meets all AAMA specification requirements for AW-PG100 fixed windows. The interior-glazed, flush design offered in this thermal window series results in a sleek, modern visual. The sashes are also mitered, corner keyed, and crimped for increased strength. If your projects are driven by the need for energy-efficient windows, select the high-performing Series 3250XT. To take the next step and gather more details, contact your Direct Assistance™ rep.

Case Study: Boyd Series 3250XT & The 2030 Challenge

Boyd Series 3250XTF Fixed Window Advantages:

• 39mm extra-wide polyamide crimped-in-place structural thermal barrier for extremely low U-Values
• 3.25" frame depth
• Interior glazed
• Structural wall areas are .125" thick for durability
• Snap-in glazing bead
• Blast resistant capabilities
• 1.0" and 1.75" glazing
• .5" glass bite
• Presents a sleek, flush, glazed appearance
• Full range of panning, receptor systems, caulk backers, mullions, and snap trims
